I.Brief Instruction of large format printer unit:
Eco Solvent Printer is one of our hot sale model since 2013.
Eco solvent printers gained good popularity among our domestic market and oversea dealers with it's fashionable outlook, stable performance, wide application range and cost effective features.
II.Advantages of large format printer unit:
1.International well-known brand guide
THK Guide:High speed, mute, high precision, high straightness
2.Motor:Original Leadshine Brushless Motor
3.Ink station :Ink stack adopts strike-touch cap station design and easy to adjust.
4.High Quality Press Wheel and Guide Table Set Design
III.Technical Parameters of large format printer unit:
|
Model |
M16S/M18S |
|
|
Print Head |
1or 2 Epson Dx11 ;Dx5; Dx7 |
|
|
Printing/Feeding Width |
1520mm; 1800mm/1830mm |
|
|
Ink |
Ink Type |
Eco solvent ink Indoor ink, sublimation ink,Uv ink,etc |
|
Color |
C/M/Y/K |
|
|
Ink Tank Volume |
1000ml tank for each color |
|
|
Supply Type |
negative pressure continuous ink supply |
|
|
Media |
Indoor Media |
PP self-adhesive vinyl, back lit film, photo paper, movable PP self-adhesive vinyl, photo cloth etc. |
|
Eco solvent Media |
PVC flex banner, car sticker, reflective film, canvas, photo paper, PP paper, PVC cold lamination film etc. |
|
|
Print Speed |
Sketch Mode |
36.9m2/h |
|
Production Mode |
28.6m2/h |
|
|
Accuracy Mode |
23m2/h |
|
|
Drying System |
fans(optional) |
|
|
Head Cleaning |
Automatic cleaning |
|
|
Heating System |
Fore /middle / after heating |
|
|
Platform Suction Regulation |
Standard |
|
|
Take up system |
Semi-automatic |
|
|
Print Interface |
Network port printing |
|
|
Operating System |
WinXP /Win7/win10 |
|
|
Printing Software |
Maintop(Main)/Photoprint (optional) |
|
|
Operating Environment |
Best Operating temperature:15°C—30°C Relative humidity:40%—60% |
|
|
Power Supply |
AC—220V,50Hz/60Hz |
|
|
Power(W) |
800W |
|
|
Package Weight /Size |
255±5%kg/3500×820×500mm |
|
|
Machine Weight /Size |
195±5%kg/3412×455×1300mm |
|
large format printer unit working photo
IV. Main parts of large format printer unit:
1.Printer heads and Capping station :
Original Epson Print Head DX5/DX11/5113/Dx7 for best speed/color/cost concern choices
Automatic lift capping controlled by motor, easy for print head cleaning & protection
Easy maintenance with easy disassemble cover
2.Noiseless Rail
HIWIN Noiseless Rail. Fixed with 20 screws to ensure print head carriage movement Fast, Steady and Stable, thus enhance print accuracy
High density press wheels and air suction bed to make sure material feeding steady and precise
High quality driver-free No encryption boards set.Easy to install, use and maintain Back and front heating bed with front fans for instant drying of printing image
3.Control panel :
Chinese/English control panel system for easy cooperation of the printer.
Ethernet port connection for much higher data transmission to support faster print speed
Brushless motor to ensure long time printing stability and accuracy
About Us:
Zhengzhou Lecai Science and Technology Co,. Ltd, known as Locor, is among the first inkjet printer factories since 2005 in China before US NOVAJET. In the past 13 years, Lecai has sucessfully developed global distribution system with popular high quality brands " Easyjet" "Deluxejet" and "Ultrajet" series.
To better serve our global customers, we set up branch company, Hongcai Digital Technology Co,. LTD, with our Factory Direct Supply brands Macroprint and Mimage.
In the past 5 years, Macroprint and Mimage have gained great popularity in dometic market with stable performace and cost effetive features for online business, and now we hope these 2 brands will serve global customers for a better printing business !
Looking forward to have long term business with you !
Our Factory view:
Professional & experienced professors, engineers and designers team dedicated to our printer mechanical design, color performance and durance etc. research and development for best using experience of our printers.
Presently we have 4 main printer production line in China mainland to meet our dealers&end users quantity demands.
Zhengzhou factory is our headquarter and administative centre.
OEM/ODM service available based on mutual agreements.
Oversea warehouse :
We have Nigeria and Ghana warehouse ,Clients can see machines there .After payment , can pick up machines without any further cost .
1 Year Warranty for printer
3 Years Warranty for borads ,More than 13 years rich production experience
Pre-Sales professional team for quotations & solution suggestions for outdoor&indoor / sublimation/UV flatbed business
After-Sales professional engineers for technical support and solutions
